Products

MotionStar

MotionStar is a vision system specifically designed for mobile applications. The high-speed shutter control, weatherproof rugged construction, super bright search light (IR or visible), fast frame rate, extended temperature range, small size and built-in intelligence make MotionStar an ideal solution for almost every application that requires speed, performance and ruggedization.
Features
  • Built with JFT's IntelliPixel technology
  • Weatherproof (IP67)
  • Shock-resistant design
  • Extended operating temperature range (-55c to 85c)
  • Color or BW sensor
  • LED long-range IR or visible searchlight synchronized to camera shutter
  • Compact system size
  • Multiple digital video and control I/O's such as 100BastT Ethernet, USB2.0, LVDS, RS422 and RS232
  • Multiple analog video output formats include NTSC, PAL and RS170
  • True synchronous snap electronics shutter to eliminate image blurring and distortion associated with fast motion
  • Automatic or software controllable exposure and gain
  • JFT's proprietary SnapFilter allows on the fly change of optical filter
  • Built-in image processor
  • Built-in frame buffer to eliminate the need for an external frame capture card
  • Progressive scan
  • Fast frame rate, adjustable on the fly
  • Built-in gamma lookup table for best image quality
Applications
  • Vehicle
  • Ship
  • Train
  • Police Patrol
  • Military
  • Avionics
  • Object Tracking
  • Laser Tracking
  • Sports
  • Plant Automation
  • Security
  • Land Survey
  • Communication
  • Military
  • Simulation and Training

MTracker2D

MTracker2D consists of two or more synchronized IntelliPixel cameras configured into line scan mode, which can be used as building block for customer's 2 dimensional object detection plane. The position of a flying or moving object intersecting with the plane can be detected.
Features
  • Built with IntelliPixel technology
  • High precision and real-time object detection
  • Interfaces including 100BastT Ethernet, USB2.0, RS422 and RS232
  • Indoor or outdoor (IP67)
  • Easy to setup
  • Genlockable with external sync source
  • Support customer's illuminator synchronized with camera shutter
  • Dual-mode filter to eliminate sunlight interference
Applications
  • Tracking flying objects
  • Sports
  • Shooting ranges

MTracker3D

MTracker3D is a professional camera system for motion capturing application, it offers the best price performance in the industry. Up to 14 cameras can be networked and synchronized for high accurate tracking. Simple API functions and real time hardware centroid calculation allow user to build their own application specific motion capturing system. MTracker3D is bundled by Innovation-Systems Inc. with the newest MaxPro software.
Features
  • Built with IntelliPixel technology
  • High accurate passive marker tracking (0.05mrad)
  • Built-in image processing to calculate marker centroid in real-time
  • Marker information includes centroid, size, intensity, orientation, etc.
  • Ethernet interface. All cameras are daisy chained by a single cable (with in line power) to simply installation
  • Support both in line digital video or analog video output
  • All cameras are gen-locked, all marker information is time stamped.
  • Built-in IR or visible light illuminator synchronized with camera shutter
  • True synchronous snap shutter to eliminate image blurring and distortion with fast moving objects
  • Automatic or software controllable exposure and gain
  • Enhanced IR sensitivity
  • Adjustable frame speed and fast frame rate supported
Applications
  • Motion Capturing and Object Tracking
  • Entertainment
  • Spots
  • Biomechanics
  • Industrial
  • Simulation and Training

RayFinder

Based on JFT's IntelliPixel technology, RayFinder is the most accurate optical position sensing system, it provides perfect solutions for applications such as firearms training simulation, object tracking, microscopic motion detection, sports, military and industrial control.
Features
  • Built with IntelliPixel technology
  • High accurate object or laser tracking
  • Built-in image processing to calculate the position and trajectory of still or moving objects
  • Real-time laser tracking, spot information include centroid, size, intensity, orientation, etc.
  • Large internal memory capable of recording sequences of events
  • Multiple digital video and control interfaces including 100BastT Ethernet, USB2.0, LVDS, RS422 and RS232
  • Multiple analog video output formats include NTSC, PAL, and RS170
  • Genlockable with external sync source
  • Allowing master/slave chaining for multiple camera applications
  • True synchronous snap shutter to eliminate image blurring and distortion with fast-moving objects
  • Automatic or software controllable exposure and gain
  • Enhanced IR sensitivity
  • Gain compensation technology to assure uniform light sensitivity between edge and center of the image sensor
  • Support long integration time
  • Progressive scan
  • Adjustable frame speed and fast frame rate supported (10 fps – 400 fps)
  • Built-in gamma lookup table
  • Proprietary SnapFilter allows on the fly change of optical filter
Applications
  • Object Tracking
  • Laser Tracking
  • Sports
  • Plant Automation
  • Security
  • Land Survey
  • Communication
  • Military
  • Simulation and Training

MaxPro

MaxPro is the motion capturing software developed by Innovation-Systems Inc..
Features
  • Video overlay
  • Interpolation
  • Filters
  • Graphs
  • Analysis/Calculations (tools), angles, velocity, acceleration
  • QuickID for marker identification
  • Marker lists with name, size and color + stick figure definition
  • Delete or filter out short trajectories
  • Hide/Show all buttons for identified and unidentified tables
  • Integration of analog and force
  • Creates C3D and ASCII files
  • Use up to 16 cameras

CrystalCam

CrystalCams are low cost general purpose cameras developed by the partners of JF Technology, Inc. These cameras include monochrome, color, PAL, NTSC, board cameras and cased cameras. Please contact sales with your requirements for recommendations.

Position Tracking System

Based on IntelliPixel platform, JC1505-OD is a real-time position tracking system for out-door applications. The system can support both area scans and line scans with a very high frame rate and accuracy. In addition to position tracking, it also performs data fusion with built-in sensors such as 6 axis gyroscope/accelerometer, magnetometer, and temperature sensor. With its powerful internal CPU and hardware image processor, JC1505-OD can handle the most versatile and demanding out-door tracking tasks. To facilitate the development of user applications, the system also supports open source and customization.
Features
  • WIFI interface
  • Support both proprietary image sensors and MIPI based
  • COTS images sensors
  • Area scan or line scan, 10-4800 FPS
  • 1 to 200 markers or LED’s
  • Low latency marker detection, extraction and streaming
  • 0.02 mRad accuracy (assuming 700 H-FOV)
  • Marker information includes centroid, size, average intensity and orientation
  • Software controllable gain, exposure, frame rate and threshold
  • Uncompressed digital image can be streamed
  • Enhanced NIR performance to 1100 nm
  • True global shutter to eliminate image blurring and distortion
  • The system can simultaneously record high speed video while streaming out marker information
  • Sun light and background suppression make the system ideal for outdoor applications
  • IMU data sampling rate from 60 to 500Hz
  • Battery life > 8 hours
  • IP67
  • Built-in IR illuminator
  • Built-in solar panel for our door battery charging
  • Open source architecture
  • Supports multi-camera networked
  • Supports customization
Applications
Biomechanical AnalysisWe offer Visual3D for biomechanical analysis. Our advanced modeling and research software supports kinematics, inverse dynamics and inverse kinematics, reporting automation, sophisticated data management and graphing. The system supports flexible
